The SLIM EASY TRANS PLUS transport system has been designed for handling porcelain sheets with a maximum thickness of 6mm.

Thanks to the system of retractable reinforced aluminium profiles, the SLIM EASY TRANS PLUS conveyor can handle porcelain sheets up to a maximum length of 320cm. These retractable profiles can be adjusted in length from 165cm to a maximum of 315cm.

The adjustable handles incorporate soft-grip handles for greater ergonomics and comfort during handling. The SLIM EASY TRANS PLUS carrier handles slide in and out through the top slot of the retractable guides making it easy to store and transport the entire system.

The transport capacity of the SLIM EASY TRANS PLUS is 80kg, but if the SLIM EASY TRANS TRANSOM SET (ref. 18819) is added, the load capacity increases to a maximum of 120kg. With the use of the CROSSBAR SET (ref. 18819) in the SLIM EASY TRANS PLUS conveyor, the system is compatible with the SLAB TRANSPORTER CART (ref.18934).

The SLIM EASY TRANS PLUS conveyor incorporates 6 vacuum suction cups with a diameter of 20cm and a high load and holding capacity. The suction cups can slide and configure their position according to the format of the porcelain sheet. The vacuum suction cup provides a safety and reliability bonus when fixing the material.

NOTE: Adding more suction cups does not increase the maximum load capacity of the SLIM EASY TRANS PLUS conveyor. The SLIM EASY TRANS PLUS conveyor suction cups are not compatible with the SLIM EASY TRANS conveyor (ref. 18910), nor are the SLIM EASY TRANS suction cups compatible with the SLIM EASY TRANS PLUS.

RUBI recommends the use of the TRANSPORTER CART and individual safety elements when handling heavy loads. The handling of these materials must be carried out by the number of people necessary according to the maximum single-person load values.
